Brand

TP-Link

Model

Archer C50

Details

Standards

IEEE 802.11n/g/b 2.4 GHz
IEEE 802.11ac/n/a 5 GHz

Network Protocols

Supports IPv4 and IPv6

Security

64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK encryption

WPA/WPA2

WPA2

WAN Ports

1 x 10/100M WAN; 4 x 10/100M LAN

LAN Ports

4 x 10/100M

Buttons

WPS / Reset Button
Wireless On / Off Button
Power On / Off Button

Wireless Data Rates

2.4 GHz: Up to 300 Mbps
5 GHz: Up to 867 Mbps

Frequency Band

2.4 GHz / 5 GHz

Antenna

2 x Dual Band External Antenna

Transmitted Power

FCC: <30 dBm

Receiver Sensitivity

5 GHz:
11a 54M: -77dBm
11ac VHT20 MCS8: -70 dBm
11ac VHT40 MCS9: -66 dBm
11ac VHT80 MCS9: -62 dBm
2.4 GHz:
11g 5.5M: -94 dBm
11g 54M: -78 dBm
11n HT20 MCS7: -75 dBm
11n HT40 MCS7: -72 dBm

Interface

USB 2.0

VPN support

PPTP, L2TP, IPSec

Power Adapter

12V DC / 1.5A

System Requirements

Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, Windows 8 / 8.1 / 10
MAC OS, NetWare, UNIX or Linux

Dimensions

1.26" x 7.20" x 4.86"

Temperature

Operating Temperature: 0 ~ 40 degree Celsius (32 ~ 104 degree Fahrenheit)
Storage Temperature: -40 ~ 70 degree Celsius (-40 ~ 158 degree Fahrenheit)

Humidity

Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing

Features

Features

Supports 802.11ac standard - the next generation of Wi-Fi

Simultaneous 2.4 GHz 300 Mbps and 5 GHz 867 Mbps connections for 1.2 Gbps of total available bandwidth

2 dual band external antennas provide stable wireless connections and optimal coverage

USB Port - easily share a printer locally and files & media with networked devices or remotely via FTP server

Easy network management at your fingertips with TP-LINK Tether

Packaging

Package Contents

AC1200 Wireless Dual Band Router Archer C50
Power supply unit
Resource CD
Ethernet Cable
Quick Installation Guide
