UPC

889523018101

GENERAL SPECIFICATIONS

Packaging

Retail

Microsoft Certifications

Windows 10 Ready

CHIPSET

Manageability

ACPI 5.0

BIOS

128 Mbit flash

CPU SUPPORT

Socket Type

AM4

AMD CPU Support

Ryzen

MEMORY SPECIFICATIONS

Maximum Memory Supported Per Slot

32GB

Memory Type

DDR4-2133
DDR4-2400
DDR4-2667
DDR4-2933
DDR4-3200

Memory Speeds Supported

4000(O.C.), 3866(O.C.), 3800(O.C.), 3733(O.C.), 3600(O.C.), 3466(O.C.), 3400(O.C.), 3333(O.C.), 3300(O.C.), 3200, 2933, 2667, 2400, 2133

Memory Slots

4 x 288pin DIMM

Max Memory Supported

128GB

Memory Channel Support

Quad Channel

VIDEO SPECIFICATIONS

Video Memory

Shared Video Memory (up to 16GB)

Onboard Graphic Chipset

Requires CPU with Integrated Graphics

STORAGE SPECIFICATIONS

M.2 Port Type

2242
2260
2280
22110

RAID Support

RAID 0
RAID 1
RAID 10

AUDIO SPECIFICATIONS

Audio Chipset

Realtek ALC1200

Audio Channels

5.1

NETWORKING

LAN Chipset

Intel GbE Lan

LAN Speed

10/100/1000Mbps

EXPANSION SLOTS

PCI Express 4.0 x16

2

PCI Express x1

2

BACK PANEL PORTS

LAN Ports

1 x 10/100/1000 RJ-45 LAN

Audio Ports

1 x 3.5 mm Microphone
1 x 3.5 mm Line-In
1 x 3.5 mm Rear Speaker
1 x 3.5 mm Subwoofer

USB 2.0

4 x USB 2.0 (Type-A)

USB 3.1

2 x USB 3.1 (Gen 2 Type-A)
4 x USB 3.1 (Gen 1 Type-A)

Video Connectors

1 x HDMI 1.4

Digital Audio

1 x Optical

INTERNAL I/O & CONNECTORS

Headers

1 x CPU Fan Header
2 x RGB Header

USB

2 x USB 2.0 Headers (supports 2 additional USB 2.0 ports)
2 x USB 3.1 Headers (supports 2 additional USB 3.1 Gen1 ports)

POWER

Power Connectors

1 x 24-pin ATX Connector

ATX Connector

24-pin

PHYSICAL SPECIFICATIONS

Depth

9.61 in. (244.00 mm)

Width

12.01 in. (305.00 mm)

Form Factor

ATX

WARRANTY

Parts

3 Years

Labor

3 Years
