TUV / CB (62368) / CE / FCC / RCM / cTUVus / WEEE / RoHS / Compliance with ErP Lot 3 2014 Requirement
Max PSU Length
140 mm
Connectors
1 x 24-pin ATX 2 x 8-Pin EPS (4+4) 6 x 8-Pin PCIe (6+2) 9 x SATA 4 x Four-Pin Peripheral 1 x Floppy
Features
Features
80 PLUS Gold certified, with 91% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads
100% Japanese Capacitors ensure long-term reliability
Fully Modular to reduce clutter and improve airflow
Full-bridge LLC Resonant Converter and DC-DC design leads to tight voltage regulation and low ripple & noise
Fluid Dynamic Bearing Fan for ultra-quiet operation and increased lifespan.
EVGA ECO Intelligent Thermal Control System eliminates fan noise at low to medium loads
Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), Dual OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)
Active Power Factor Correction
Dimension & Weight
Dimensions
3.40" x 5.90" x 5.50"
Package
Package Content
Cable: ATX Cable: 1 x 600mm (m) EPS Cable: 2 x 700mm (m) PCIe Cable: 2 x 700mm, 2 x 700mm, 820mm (m) SATA Cable: 3 x 550mm, 650mm, 750mm (m) Four-Pin Peripheral Cable: 1 x 550mm, 650mm, 750mm, 850mm (m) Floppy Adapter: 1 x 100mm AC Power: 1 x 1500mm (m)
