CPU SOCKET

LGA2066, LGA2011-v3, LGA2011, LGA1366, LGA1200, LGA1156, LGA1155, LGA1151, LGA1150, AM4, AM3+, AM3, AM2+, AM2, FM2+, FM2, FM1

DIMENSIONS (L X W X H)

120 x 80 x 159 mm / 4.7 x 3.1 x 6.3 inch

HEAT SINK DIMENSIONS (L X W X H)

116 x 51 x 159 mm / 4.6 x 2.0 x 6.3 inch

HEAT SINK MATERIAL

Aluminum Fins, 4 Direct Contact Heat Pipes

HEAT SINK WEIGHT

465g / 1.03lb

HEAT PIPE DIMENSIONS

Ø6mm

FAN DIMENSIONS (L X W X H)

120 x 120 x 25 mm / 4.7 x 4.7 x 1 inch

FAN SPEED

600-2000 RPM (PWM) ± 10%, 600-1600 RPM (PWM) ± 10% (EU Version)

FAN AIRFLOW

24.9 - 82.9 CFM ± 10%, 24.9 – 66.3 CFM ± 10% (EU Version)

FAN AIR PRESSURE

0.3 - 2.7 mmH2O ± 10%, 0.3 - 1.7 mmH2O ± 10% (EU Version)

FAN LIFE EXPECTANCY

40,000 Hours

FAN NOISE LEVEL

9 - 36 dBA, 9 - 31 dBA (EU Version)

FAN BEARING TYPE

Long Life Sleeve Bearing

CONNECTOR

4-Pin

FAN RATED VOLTAGE

12VDC

FAN RATED CURRENT

0.22A, 0.19A (EU Version)

FAN POWER CONSUMPTION

2.64W, 2.28W (EU Version)

FAN WEIGHT

104g / 0.23lb

NOTE

*AMD AM4 upgrade kit needed, please visit: http://bit.ly/31244ne, *The supplied accessories may differ by country or area. Please check with your local distributor for further details.

COOLER TYPE

Air Cooler

SERIES

Hyper

HEATPIPES

4
